SKU / Part #: EFM3709T
Category: 10. FBO Supplies; Ground Support & Parts > 10d: Parts & Accessories
Description:
The EFM3709T AC Motor by Baldor is a robust 7.5 HP, 3-phase motor designed for demanding industrial applications, including fueling systems and ground support equipment. With a Totally Enclosed Fan Cooled (TEFC) steel enclosure, it offers protection against environmental contaminants. Operating at 3520 RPM with high efficiency at 89.5%, it ensures reliable performance and energy savings. This is a close-out item with limited stock available?act fast to secure yours.
Technical Description:
- Horsepower: 7.5 HP
- Speed: 3520 RPM
- Voltage: 230/460 V
- Amperage: 18/9 A
- Phase: 3-phase
- Frequency: 60 Hz
- Frame: 213T
- Enclosure: TEFC (Totally Enclosed Fan Cooled)
- Efficiency: 89.5%
- Insulation Class: F
- Mounting: Base mount
- Rotation: Reversible
- Shaft Diameter: 1-3/8″
- Overall Length: 17.91″
- Service Factor: 1.15
- Duty Cycle: Continuous
- Bearings: Ball
- Manufacturer Model #: 37A006R224G1
- Maximum Ambient Temperature: 40? C
- Ship Weight: 115 lbs.
